EEVblog 1545 - R&S MXO4 TEARDOWN. The World's Fastest Oscilloscope!

Video Description

The world's fastest oscilloscope, the Rohde & Schwarz MXO4 teardown! Wow, this is an impressive beast in more ways than one. https://www.rohde-schwarz.com/us/products/test-and-measurement/oscilloscopes/rs-mxo-4-oscilloscope_63493-1164992.html Teardown photos: https://www.eevblog.com/2023/05/25/eevblog-1545-worlds-fastest-oscilloscope-mxo4-teardown/ Unboxing and testing: https://www.youtube.com/watch?v=txPxo4TA0i4 ADC: https://www.ti.com/lit/ds/slvsdr3c/slvsdr3c.pdf FPGA: https://www.digikey.com/en/products/detail/amd-xilinx/XCZU7EG-1FBVB900I/7034695 Forum: https://www.eevblog.com/forum/blog/eevblog-1545-worlds-fastest-oscilloscope-mxo4-teardown/ 00:00 - Rohde & Schwarz MXO4 The world's fastest oscilloscope 00:55 - The handle doesn't cut the mustard these days 02:02 - The production flap 03:54 - ALL scopes should use this power connection! 04:32 - This is gorgeous, and it just gets better. 06:38 - Look at it! Look at it! 08:14 - RF goodness 08:35 - Dual 100MHz Arb generator 08:54 - Best probe interface solution ever 09:55 - The world's best low noise fan? 10:53 - Main PCB 13:17 - Inside the front end RF can 19:48 - The MXO4-EP ASIC 21:30 - External trigger system 22:43 - $3300 12bit ADC 23:29 - The $3400 Xilinx Zynq FPGA and applications processor. 26:08 - I'm now uploading videos natively on Twitter If you find my videos useful you may consider supporting the EEVblog on Patreon: http://www.patreon.com/eevblog Web Site: http://www.eevblog.com Other channels: EEVblog2: http://www.youtube.com/EEVblog2 EEVdiscover: https://www.youtube.com/eevdiscover T-Shirts: http://teespring.com/stores/eevblog #ElectronicsCreators #Oscilloscope #Teardown
