Video Description

12v DC to 220v AC converter DIY, 12v to 220v power inverter using D718. A simple circuit is shown that transforms 12V DC power into 220V AC power. This allows you to power common household appliances using a car battery or other 12V source. how to build an inverter Components used in this project:– 1. 12 0 12 / 5A, Transformer. 2. D718 Transistors. 3. TIP41C Transistors. 4. 330 Ohm 2W. 5. 1K 2W Resistors. 0:00 - Circuit Assemble. 4:22 - Using Chopper Transformer. 7:22 - Using 12 0 12 Transformer. 8:44 - Power in to Inverter. 9:11 - Checking Wave form. #12v_to_220v_inverter #12vto220vinverter #diyinverter #dctoacconverter #homemade101
