Building a Plasma Flame Generator , HFSSTC Class E Tesla Coil
About
No channel description available.
Latest Posts
Video Description
This project is sponsored by PCBWAY https://www.pcbway.com/?from=MirkoP 11th anniversary celebration: https://www.pcbway.com/activity/anniversary11th.html This is the plasma flame generator, based on a Class-E RF power amplifier Tesla coil, offers a fascinating and relatively safe way to create a continuous plasma discharge. With careful tuning, this device can produce a stable plasma flame with interesting properties, demonstrating the powerful effects of high-frequency, high-voltage electricity. SAFETY NOTE: Please do not attempt to recreate the experiments shown on this video unless you are familiar with High Voltage Safety Techniques! Direct Current even above 60V maybe lethal, even when the AC supply voltage has been disconnected due to the stored energy in the capacitors. I have no responsibility on any hazards caused by the circuit. Be very careful. This is a humble request. Detailed instructions and schematic at: https://www.hackster.io/mircemk/building-a-plasma-flame-generator-hfsstc-class-e-tesla-coil-36e69f Chapters: 0:06 Short Demo 1:48 Description 3:09 Schematic 5:37 Different scondaries 6:20 First test 8:49 Increasing voltage 11:53 Demonstration 16:05 On Oscilloscope 17:11 Conclusion 17:39 Safety note 18:05 Building If you are interested in this area, see the Playlist at: https://www.youtube.com/watch?v=q23l0UyrSP4&list=PLAxrqEdgtyUV5SriPejNitf6dWFyW8zPQ If you like my job buy me a coffee: https://ko-fi.com/mircemk Visit my Youtube Channel for more Projects , DIY and How To Make videos: https://www.youtube.com/c/MirkoPavleskiMK/videos by mircemk SUBSCRIBE LIKE AND SHARE !!!! Thanks for your Support ! #highvoltage #plasmaflame #teslacoil #pcbway
