DIY Powerful Bass Amplifier 200 Watts Using C5200 and A1943 With NE5532 IC

Video Description

➤ In today's video, the power amplifier using C5200 and A1943 transistors with 5532 IC. This circuit can be used for guitars. ➤ Powerful Amplifier 200 Watts Using C5200 and A1943 With NE5532 IC ➤ Copyright © by Share Tech Creative ➤ Follow me: https://www.youtube.com/c/ShareTechCreative… ➤ Follow Facebook: https://bit.ly/3eEHjNb ➤ 📺 Thanks for watching! ➤Schematic diagram: https://photos.app.goo.gl/owNKrjTCipDx5vEj9 ➤ Parts Required: Transistor: – 2SC5200 x 2 – 2SA1943 x 2 – TIP 41 – TIP 42 – NE5532 IC Capacitor: – 33p – 0.0022uF – 0.022uF – 0.01uF – 0.1uF x 2 – 1uF/50v x 3 – 47uF/50v x 4 Resistors: – 0.47/5W x 4 – 10R/1W – 100R/1W x 4 – 220R/1W x 2 – 820R x 2 – 1K x 4 – 1K5 x 2 – 10K x 1 – 15K x 4 – 33K x 2 – 100K x 1 – 50k x 3 potentiometer – Aluminum heatsink – Mica pads x 4 – Diode 4007 x 2 – Diode Zener 15V x 2 Power supply: +35V _0V_ -35V / 10A transformer #diyamplifier #amplifier200watt #sharetechcreative
