EEVblog 1438 - The TOP 5 Jellybean Regulators & References

Video Description

Dave looks at his TOP 5 (plus change) Jellybean Voltage Regulators and References, and explains why you need to know them. 00:00 - Jellybean Voltage Regulator & References 01:52 - 78xx Linear Voltage Regulator 08:01 - Adjustable Voltage Regulator 13:52 - 1117 Low Dropout Regulator 15:21 - LDO Stability 20:01 - LM4040/4041 Voltage Reference 24:38 - Using a Reference as a Regulator 30:53 - TL431 Voltage Reference 38:58 - Use as a PSU regulator 40:43 - Beware of Stability 41:43 - REF01 a better Voltage Reference LM7805: https://www.ti.com/lit/ds/symlink/lm340.pdf LM317: https://www.ti.com/lit/ds/symlink/lm117.pdf LM317L: https://www.ti.com/lit/ds/symlink/lm317l-n.pdf 1117: https://www.ti.com/lit/ds/symlink/tlv1117.pdf LM4040/4041: https://ww1.microchip.com/downloads/en/DeviceDoc/LM4040-41-Precision-Micropower-Shunt-Voltage-Reference-DS20005757B.pdf TL431: https://www.ti.com/lit/ds/symlink/tl431.pdf REF01: https://www.analog.com/media/en/technical-documentation/data-sheets/REF01_02_03.pdf TL431 Design: http://www.ti.com/lit/pdf/slva685 Uuderstanding LT431 Stability: https://www.ti.com/lit/an/slva482a/slva482a.pdf The TL431 in Switching Controllers: https://www.onsemi.com/pub/Collateral/TND381-D.PDF Forum: https://www.eevblog.com/forum/blog/eevblog-1438-the-top-5-jellybean-regulators-references/ Subscribe on Odysee: https://odysee.com/@eevblog:7 EEVblog Web Site: http://www.eevblog.com The 2nd EEVblog Channel: http://www.youtube.com/EEVblog2 EEVdiscover: https://www.youtube.com/eevdiscover Support the EEVblog through Patreon! http://www.patreon.com/eevblog AliExpress Affiliate: http://s.click.aliexpress.com/e/c2LRpe8g Buy anything through that link and Dave gets a commission at no cost to you. Donate With Bitcoin & Other Crypto Currencies! https://www.eevblog.com/crypto-currency/ T-Shirts: http://teespring.com/stores/eevblog #ElectronicsCreators #Jellybean
