ESP32: Plot graphs through a webserver/webportal (WiFi Part 4) - Arduino

MoThunderz September 10, 2022
Video Thumbnail
MoThunderz Logo

MoThunderz

@mothunderz

About

Music, programming, Arduino, ESP32, analog synths (Roland, Arp, etc) and other fun stuff Have fun! Sander

Video Description

This video shows how to plot graphs / charts in real-time with the ESP32 webserver/webportal. This will allow you for instance to plot sensor values over time when using the ESP32 as IoT gateway. This video expands on the webserver code explained in part 3: https://youtu.be/ZJnXKD0LqDo Starting point for coding along is: https://github.com/mo-thunderz/Esp32WifiPart3 Final code can be downloaded from: https://github.com/mo-thunderz/Esp32WifiPart4 Libraries required for ESPAsyncWebServer: https://github.com/me-no-dev/ESPAsyncWebServer https://github.com/me-no-dev/AsyncTCP Libraries required to make SPIFFS.h work: ||-- Please use Arduino IDE 1.x -- the SPIFFS.h library is not supported under IDE 2.x --|| https://github.com/me-no-dev/arduino-esp32fs-plugin/releases/ Favicon downloaded from: https://icons8.com/icons/set/favicon Here the explanation on how to setup the ESP32 as Access Point: https://youtu.be/PGt_5xQo2_0 If you have problems connecting the ESP32 to your router, see part 1: https://youtu.be/0AlATlN95Y0 Might you have problems programming the ESP32, pls refer to: https://youtu.be/xQkE0eDImkE Correction: 09:00 Note that the SPIFFS library only works under Arduino IDE 1.x. To date no support of IDE 2.x is available.
