How to size wires and fuses for a solar electric system
EnergyUME
View ChannelAbout
UMD’s Maryland Energy Extension (MEE) delivers unbiased and research-based programming to facilitate sustainable energy decisions throughout the state. This institution is an equal opportunity provider. Accommodation request, contact your local UMD Extension Office.
Latest Posts
No results found. Try different keywords.
Video Description
Learn how to size wires and fuses for your solar electric system. ⏱️Timestamps: 0:06 Intro 1:10 Wire sizes and AWG ratings 1:57 Wire insulation 4:12 Wire colors 4:52 Review of over current protection devices (OCPDs) 5:52 Maximum current for panel output 7:16 Maximum current for inverter output 7:55 Maximum current for battery-based inverter 8:55 Ampacity 9:21 Voltage drop calculation 10:44 Current overload considerations 11:04 Continuous duty safety factor 12:41 Other videos and resources 🗎 Publication: Working on Solar Wiring and Fusing (EB-2023-0676) https://go.umd.edu/EB-2023-0676 For more information, visit: http://go.umd.edu/FarmSolar
