I completely restored an IBM ThinkPad Tablet from 1993

polymatt November 17, 2024
Video Thumbnail
polymatt Logo

polymatt

@polymatt

About

I'm a tinkerer and collector of skills. I hope others get as much out of my videos as I've gotten from the YouTube community. Want to participate or ask questions and know more about the content in my videos? Subscribe to my Patreon!

Video Description

Thanks to https://pcbway.com for sponsoring this video. After picking this thing up at VCF Southwest this past year, I didn't know what I was getting into, but I knew it wasn't going to be easy. This is one of the first IBM machines to bear the ThinkPad name. It's a 730T 486 tablet computer from 1993 - and it needs a lot of work... Sponsor: For 3D Printing, CNC machining and more, head to https://pcbway.com for a range of manufacturing services. Software: 3D Modeling - Shapr3D https://www.shapr3d.com/ (use code MATT10 for 10% off) Models: Bezel - https://www.printables.com/model/1077920-ibm-thinkpad-730t-top-bezel Battery - https://www.printables.com/model/1077913-ibm-thinkpad-730t-battery-enclosure PCMCIA Door - https://www.printables.com/model/1077924-ibm-thinkpad-730t-tablet-pcmdia-door Pen holder / Door - https://www.printables.com/model/1077928-ibm-thinkpad-730t-tablet-pen-holder-cover Strip Cutter - https://cults3d.com/en/3d-model/tool/balsa-cutter-3mm-and-5mm Chapters: 0:00 - Coming up... 0:16 - Introduction 1:29 - Booting it up 3:09 - Replacing the LCD 5:18 - 3D Modeling a new frame 7:37 - Re-building the LCD assembly 11:28 - Making a new LCD cable 13:27 - Recapping the LCD 14:14 - Replacing the CCFL Backlight 15:50 - The system board 17:38 - 3D Modeling a new Bezel 20:35 - Cleaning the case 21:44 - Recreating the decals 25:02 - Finishing touches 27:27 - Making new batteries 31:13 - Final touches 32:52 - Final thoughts Music: (All music is licensed through Epidemic Sound unless otherwise stated) Polymatt Intro & Outro theme - @banjoguyollie Unfinished Stories - Lennon Hutton Spider Theory - Sage Oursler Conspiracy Inc - Alec Slayne Bending Dreams - Charles Holme No More Reasons - Farrell Wooten The Narrator - Philip Ayers Who We Are - Gavin Luke Glitch in Reality - David Celeste All Parts Equal - Gavin Luke Through the Prism - Ava Low My Moon and Your Sun - Hampus Naeselius
