Power For Your Electronics Projects - Voltage Regulators and Converters

Video Description

Learn about voltage regulators and buck converters that you can use to power up your electronic projects. Full article at https://dronebotworkshop.com/powering-your-projects/ More articles and tutorials: https://dronebotworkshop.com Join the conversation on the forum: https://forum.dronebotworkshop.com Subscribe to the newsletter and stay in touch: https://dronebotworkshop.com/subscribe/ Today we are going to look at the somewhat mundane but absolutely essential subject of supplying power for your electronic projects. Trust me, this stuff is important! Electronic devices typically require either 5 or 3.3 volts, sometimes both. Other common voltage requirements include 6 and 12 volts for motors and displays. Some complex designs (ie. a robot) require several different supplies with different current capabilities. When you build your latest robot or IoT device you’ll need to consider how you'll supply these voltages in the real world. On the workbench you can use a bench power supply if you have one, a USB adapter, or even the USB port on a computer (just like with the Arduino). But when your creation needs to exist on its own with a line-powered or battery power supply you’ll need to figure out how to get all of those voltages delivered to your components, preferably easily and inexpensively. I have nine, yes nine methods of doing exactly that. Today I’ll show you a number of different voltage regulators and converters ranging from the classic 7805 3-pin voltage regulator to a tiny device that can supply a steady 5 volts even when your battery is about to die. Check out the following Table of Contents to skip ahead to the power supply solution of your choice. Or just sit back and enjoy the show. INTRO 00:00 - Introduction 03:00 - Breadboard power supply module 06:28 - Power Supply Basics LINEAR REGULATORS 11:42 - LM7805 - 5 Volt linear regulator 14:32 - LM317 - Variable linear regulator 17:52 - PSM-165 - 3.3 Volt linear regulator module 19:47 - AMS1117 - 5 Volt linear regulator module 21:43 - L4931CZ33-AP - 3.3 volt low voltage-drop regulator VOLTAGE CONVERTERS 23:51 - Buck Converter Intro 24:41 - MINI-360 - Variable buck converter 26:46 - Boost Converter Intro 27:37 - PSM-205 - USB boost converter 29.07 - MT3608 - Variable boost converter 31:06- Buck Boost Converter Intro 33:06 - S9V11F5 - 5 Volt buck boost converter That last module is the one I was referring to earlier, it really is an amazing device and is perfect for your battery-powered projects. As with all of my videos, there is an article where you will find more details regarding all of the voltage regulators, buck converters, boost converters, and buck-boost converters mentioned here. Now go power something up!
