Raspberry Pi Pico Lecture 15: PIO Overview and Examples
V. Hunter Adams
•
September 26, 2022
V. Hunter Adams
View ChannelAbout
Lecturer, Electrical and Computer Engineering, Cornell vanhunteradams.com
Latest Posts
Video Description
0:00 - Lecture plan 1:20 - PIO block organization 5:20 - PIO state machine organization 7:50 - PIO assembly instructions 20:10 - Side setting 22:30 - Program wrapping 26:20 - FIFO joining 27:20 - Autopush and autopull 29:55 - Clock dividers 35:30 - Simple PIO example (hello pio) 56:20 - UART TX PIO example Fall, 2022 lectures from ECE 4760 (Digital Systems Design Using Microcontroller) at Cornell University. Course site: https://ece4760.github.io Hunter’s site: https://vanhunteradams.com
