Resistor Color Codes Explained with Examples

Video Description

Resistor Color coding (3 bands, 4 bands, 5 bands, and 6 bands) has been explained with Examples, What is Resistor Color Code: Resistors are usually very tiny, It is very difficult to print values on them, So color bands are printed to represent the electrical resistance, These color bands are known as resistor color codes. How to read Resistor color codes: To read them, we have to hold the resistor in the correct direction, Generally, the color band placed closest to the lead is considered as the first band and so on. Another way is the extra space between the two bands also indicates the reading direction. Basically, Resistors can have 3, 4, 5 or 6, color bands. And accordingly, they are known as the 3-band, 4-band, 5-band, and 6-band resistors respectively. 4-band Resistor Color Code: 1st Band - 1st Digit 2nd Band- 2nd Digit 3rd Band - Multiplying factor 4th Band - Tolerance 3-Band Resistor Color Code: In 4-Band Resistor, if the 4th band or the tolerance band is missing then it is known as the 3-Band Resistor, For these resistors, the tolerance value is assumed to be 20 %. 5-Band Resistor Color Code: 1st Band - 1st Digit 2nd Band- 2nd Digit 3rd Band - 3rd Digit 4th Band - Multiplying factor 5th Band - Tolerance 6-Band Resistor Color Code: 1st Band - 1st Digit 2nd Band- 2nd Digit 3rd Band - 3rd Digit 4th Band - Multiplying factor 5th Band - Tolerance 6th Band- Temperature Co-efficient of resistance (In ppm /K) Timestamps for various topics covered in this video are as follows: 0:56 How to Read or Resistor Color Codes, 2:14 How to Remember Resistor Color Code Chart, 2:59 4-Band Resistor Color Code (Examples), 6:27 3-Band Resistor Color Code (Examples), 7:30 5-Band Resistor Color Code (Examples), 9:49 6-Band Resistor Color Code (Examples), 12:42 Resistor Color Code Exceptions. This video will be helpful to all students of science and engineering in understanding resistor color coding. #ResistorColorCoding The links of related videos of Basic electronics Conductors, Insulators, and Semiconductors https://youtu.be/Em5NVbbmqKA Current, Voltage, and Power https://youtu.be/ZXeyNsZ46oU What is Resistor https://youtu.be/ZwDN5mFB1z8 Different Types of Resistors https://youtu.be/80JgLeUj1mQ Please SUBSCRIBE my youtube channel https://www.youtube.com/c/ElectronicsAD​ Music Credit: http://www.bensound.com/​​​​ "Keep Learning and Keep Growing".
