Teardown of Anker 120W GaN Charger (GaNPrime 737)

Video Description

You can buy it on Amazon: https://amzn.to/3vBtwSd If you wanna buy the tester of POWER-Z, you can visit our Amazon store: https://www.amazon.com/s?me=A31UM8SRXYVF2Z&marketplaceID=ATVPDKIKX0DER Introduction --------------------------------------------------------------- Recently, Anker held a special event and announced its best multi-device fast charging lineup, GaNPrime. And today, we got the brand new GaNPrime 120W charger, also called 737 charger. It adopts the world’s first HFB topology developed by Anker and Infineon and supports dynamic power distribution. So, let’s take it apart and see what’s inside. Bill of materials (BOM) ------------------------------------------ Time-delay Fuse: Better Electronics (5A 250V) Safety X2 Capacitor: DGCX (0.47μF) Film Capacitor: DGCX (1μF 450V) PFC Controller: ON Semiconductor NCP1623 GaN IC for PFC Boost: Navitas NV6136A (170mΩ, 700V) PFC Boost Rectifier: Pingwei MUR5JGER (5A, 600V) Bypass Diode: Pingwei GS3MB Electrolytic Capacitor: Yongming (100μF 420V) Primary Controller: Infineon XPDS2201 GaN IC: Infineon IGI60F1414A1L Optocoupler: EL1018 Synchronous Rectifier Controller: MPS Synchronous Rectifier: Infineon BSC0802LS Solid Capacitor: Yongming SMD Y Capacitor: Anshan KeiFat Protocol Chip: Ismartware SW3536 MOSFET: Infineon BSZ018N04LS6 (40V, 1.8mΩ) Buck MOSFET: Infineon VBUS MOSFET: Infineon BSZ018N04LS6 Current Sense Amplifier: SG Micro SGM8199A1 MCU: Eastsoft ES8P5066FJNK Chapter ---------------------------------- 0:00 Intro 1:33 Test 2:27 Teardown 3:49 Analysis 8:15 Summary For more details. You can visit our website: https://www.chargerlab.com SOCIALS: Instagram：https://www.instagram.com/chargerlabs/ Facebook：https://www.facebook.com/chargerlab Twitter：https://twitter.com/chargerlab For Business Inquiries: [email protected]
