Diy 1000 Watts High Power Amplifier Using Transistors 2SC5200 and 2SA1943 - V1

Video Description

The power amplifier circuit using IC HA17741 for the amplifier's input, the final transistor using 2SC5200 and 2SA1943. Output up to 500 Watt Mono, 1000 Watts for the stereo amplifier circuit. ▬▬▬▬▬▬▬▬▬▬ ۞▬▬▬▬▬▬▬▬▬▬ ➤ Copyright © by Share Tech Creative ➤ Thanks for watching my video ➤ Follow me: https://www.youtube.com/c/ShareTechCreative?view_as=subscriber=1 ➤ Follow Facebook: https://bit.ly/3eEHjNb #diyamplifier #sharetechcreative ▬▬▬▬▬▬▬▬▬▬ ۞▬▬▬▬▬▬▬▬▬▬ *****Video you may not have watched***** https://www.youtube.com/watch?v=mWC2xK7ok8Y&list=PLDdnrznxdd14NW9urnEz8jvWbDSKUjPju&index=4 ▬▬▬▬▬▬▬▬▬▬ ۞▬▬▬▬▬▬▬▬▬▬ ➤Schematic diagram: https://photos.app.goo.gl/Ypr6VnKNtwK27Aj4A Mono amplifier using: ➤ IC HA17741 x 1 ➤ 2SC2073 Transistors x 2 ➤ 2SA940 Transistors x 2 ➤ 2SC5200 Transistors x 5 ➤ 2SA1943 Transistors x 5 ➤ 0.33/5W resistors x 10 ➤ 4.7/1W resistors x 10 ➤ 10/2W resistors x 2 ➤ 100/1W resistors x 6 ➤ 330/1W resistors x 2 ➤ 10 resistors x 1 ➤ 100 resistors x 1 ➤ 1K resistors x 1 ➤ 5K6 resistors x 2 ➤ 10K resistors x 2 ➤ 47K resistors x 1 ➤ 100K resistors x 1 ➤ 33P capacitors x 1 ➤ 220P capacitors x 4 ➤ 680P capacitors x 1 ➤ 0.1uF capacitors x 1 ➤ 10uf/50v capacitors x 2 ➤ 100uf/25v capacitors x 3 ➤ 10.000uf/80v capacitors x 2 or x 4 ➤ Diode 4148 x 2 ➤ Bridge Diode 35A X 1 ➤ ZENER Diode 15V X 2 ➤ Coil 16 turn (Copper wire Ø1.5mm wrapped 16 turns of 12mm diameter) ➤ 50k Potentiometers x 1 ➤ Transistors insulation pads x 10 ➤ Aluminum heat sink x 1 ➤ Aluminum heat sink x 1( Use aluminum heatsink as big as possible :)) ➤ 45vac to 50vac x 2 / 30A transformer or larger more #diyamplifier #diy1000watts
