Reverse Engineering PCBs: Steal from the Pros

Video Description

In this video we look at how to reverse engineer professional PCB schematics so that you can re-purpose and reuse them in your own designs. Then we have the result appraised by professional PCB designer, Matt Kaiser, of Kaiser Engineering. Check out Kaiser Engineering's work at https://www.instagram.com/kaiser_engineering Waveshare ESP32-S3 LCD Driver available from https://s.click.aliexpress.com/e/_oFckgda 🩵 Join our Discord Community - https://discord.gg/86EpNjzrXQ ☕ Buy me a coffee - https://www.buymeacoffee.com/garagetinkering 00:00 Intro 01:01 Reference board 02:06 Review the schematic 05:33 Remake the schematic 22:49 Layout the PCB 43:22 Introducing Matt Kaiser 45:45 Schematic review 01:05:24 PCB review 01:17:33 Roundup
