TSP #130 - Tutorial, Experiment & Teardown of a CDM324 24GHz Doppler Radar Module

Video Description

In this episode Shahriar demonstrates a full analysis of a CDM324 24GHz Doppler radar module from IC Station. Opening the module reveals a series of microwave PCB components and several active devices. A complete analysis of the module is presented. The unit is then measured and the impact of antenna impedance and power supply voltage on the output frequency is measured. The phase noise of the output signal is also measured. Using a series of servo motors, the radiation pattern of the antenna array in both azimuth and elevation is also presented. Using the radar module the speed of a computer fan is remotely measure using an oscilloscope and FFT function. You can buy your own module from (http://www.icstation.com/). All proceedings from Patreon for this video will be donated. The Signal Path www.TheSignalPath.com www.YouTube.com/TheSignalPath www.Patreon.com/TheSignalPath
