Wankel vs Radial vs Rotary | Its Parts, Working & Applications | Explained

Video Description

Wankel Engine vs Radial Engine vs Rotary Piston Engine | Explained Video Credits (Please check out these channels also): [Matt Rittman] How a Rotary Engine Works - https://youtu.be/6BCgl2uumlI Wankel Rotary Engine: The Wankel engine is an internal combustion engine with an eccentric rotary design to convert pressure into rotating motion. In a rotary engine, the pressure of combustion is contained in a chamber formed by part of the housing and sealed in by one face of the triangular rotor, which the engine uses instead of pistons. The engine is commonly referred to as a Rotary Engine, although this name is also applied to other completely different designs, known as the ones with pistons known as a rotary piston engines. Radial Piston Engine: Radial engines have cylinders mounted radially around a central crankcase. The radial engine is a reciprocating type of internal combustion engine configuration in which the cylinders "radiate" outward from a central crankcase like the spokes of a wheel. The radial engine has pistons, valves, and spark plugs as any four-stroke engine. The big difference is in the crankshaft. Instead of the long shaft used in a multi-cylinder car engine, there is a single hub -- all of the piston's connecting rods connect to this hub. A radial engine works like any other four-stroke internal combustion engine. Each cylinder has an intake, compression, power, and exhaust stroke. Rotary Piston Engine: The Rotary piston engine is an obsolete piston engine with a rotating crankcase. A rotary engine is essentially a standard Otto cycle engine, with cylinders arranged radially around a central crankshaft like a conventional radial engine, but instead of having a fixed cylinder block with the rotating crankshaft, the crankshaft remains stationary, and the entire cylinder block rotates around it. ---- Time Stamp --- 00:00 - Introduction 00:07 - Wankel Rotary Engine 09:24 - Radial Piston Engine 14:04 - Rotary Piston Engine 15:53 - Outro Disclaimer: This video is just for educational purposes only. We are not in the auto repair business nor publish automotive service manuals. This video is not reviewed or authorized by any vehicle manufacturer. This video is intended only as general guidance. Every system is slightly different, so refer to the owner’s manual of your vehicle for any specific information about your model. Remember that only proper service and repair procedures will ensure your car's safe and reliable operation. Copyright Disclaimer: Copyright Disclaimer under section 107 of the Copyright Act 1976, allowance is made for “fair use” for purposes such as criticism, comment, news reporting, teaching, scholarship, education, and research. Fair use is a use permitted by copyright statute that might otherwise be infringing. Non-profit, educational, or personal use tips the balance favor of fair use. More Videos on Engines: 4-Stroke & 2-Stroke Engine: https://youtu.be/8dAbcbAJRw8 Car Engine Parts & Their Functions Explained: https://youtu.be/x70VqMrXrbs Follow us on Facebook:- https://www.facebook.com/fanpageengineerspost Contact us: [email protected] Visit our Website for more articles:- https://www.theengineerspost.com/ If you find this video useful, please share it with your friends, and If you have any questions, leave a comment we’ll respond. Thanks for watching, and subscribe for more.
