Can we SAVE This Cylinder with SEIZED Gland!? | Huge CAT 24M Motor Grader

Video Description

We're on a mission to rescue this cylinder and save the customer a hefty chunk of coin. This hydraulic cylinder off Caterpillar’s biggest motor grader has a seized gland and the customer has tried everything to break its stubborn grip, but nothing’s budging. Join us on a rescue mission as we turn detective, machinist, and welder all in a day! First, we start with machining a custom locking pin to get the cylinder setup in the lathe. Then we machine out the weld and remove the cylinder end before setting the cylinder up in the hydraulic press and removing the rod and damaged gland seals. Then, it's time for the main event: removing that stubborn gland without damaging the rest of the cylinder. This might sound straightforward, but there's a fine line between saving the day and creating a whole new problem. Unfortunately, the gland is seized solid and that means we have to carefully machine it out in the lathe, all the while keeping the cylinder barrel and threads in good shape. Once the gland is removed it’s time for welding the barrel end back in place, stronger than before. In just a half a day’s work, we’ll save the customer a lot of cash compared to a whole new cylinder – a win-win for everyone! In this video we are using: - Hafco TM-1740G Lathe - Hafco TM-26120G Centre lathe - WIA 500i Weldmatic welder - Metalmaster HPM-150T Hydraulic press Join our channel: We upload new videos every Friday at 5pm AEST! If you want to see more of our videos click LIKE & SUBSCRIBE! You can subscribe to our channel here: https://bit.ly/ceesubscribe Want Early Access & Ad Free videos?? Join our Patreon Community: https://www.patreon.com/cuttingedgeengineering Official CEE Merch shop: https://www.ceeshop.com.au Check out our CEE Amazon store and explore our favourite finds that we use in the workshop: https://www.amazon.com/shop/cuttingedgeengineeringaustralia To see more follow us on online here: TikTok: https://vt.tiktok.com/ZSdHhtN4h/ Instagram https://instagram.com/cutting_edge_engineering Facebook https://www.facebook.com/cuttingedgeengineeringaustralia/ About Us: We're a down-to-earth real life machining and fabrication workshop in Australia. We specialise in helping business in mining and earthmoving to keep their machines running smoothly. We love working on broken parts and the bigger the better! We upload new videos every week showcasing machining, welding, line boring, honing and all the other awesome stuff that goes down in our workshop. Learn how we tackle different projects and see the satisfaction of creating something useful. Subscribe to stay updated on our latest jobs and projects! Follow us on Patreon for even more content and behind-the-scenes glimpses or find us on Tiktok, Facebook and Instagram for a chance to connect with us. #australianmachinist #machineshop #machinist
